PlusPRO 2 Series Rack/Tower
1000VA to 3000VA
Battery Pack
Battery Pack
The PlusPRO 2BB-36V-14AH external battery pack is connected to PlusPRO 2 Series Rack/Tower 1000VA UPS models. The PlusPRO 2BB-72V-9AH external battery pack is connected to PlusPRO 2 Series LV Rack/Tower 3000VA UPS models. The PlusPRO 2BB-96V-7AH external battery pack is connected to PlusPRO 2 Series HV Rack/Tower 3000VA UPS models. External battery pack provides continuous power from the batteries for flexible runtime extension of UPS systems.
● Extended-run battery pack provide flexible runtime for UPS systems
● Advanced battery management included
● Multiple battery pack configuration
● Advanced battery management included
● Multiple battery pack configuration
| MODEL | PlusPRO 2BB-36V-14AH | PlusPRO 2BB-72V-9AH | PlusPRO 2BB-96V-7AH |
| BATTERY | |||
| Type | Maintenance-free Lead Acid battery | ||
| Voltage | 36VDC | 72VDC | 96VDC |
| Capacity | 12V/7AH*3pcs*2sets | 12V/9AH*6pcs | 12V/7AH*8pcs |
| Expected Battery Life | 3-5 years | ||
| ENVIRONMENT | |||
| Operting Temperature | 0°C-40°C (32°F-104°F) | ||
| Humidity | 0-95% (Non-condensing) | ||
| PHYSICAL | |||
| Rack Height | 2U | ||
| Dimension (D*W*H) | 480*440*90mm | ||
